Product appearance may vary. Refer to the description and specs for complete information
Manufacturing Part #
EF205-210
Availability:
2
In stock
Product type:
Overload Relays
- $718.31
- $718.31
- (-0%)
- Unit price
- per
Free standard shipping on orders over $100
| Manufacturer Part Number | ABB EF205-210 (1SAX531001R1101) |
| Current Setting Range | 63.0 to 210.0 Amps |
| Trip Class | Selectable: Class 10E, 20E, or 30E |
| Rated Operational Voltage | 1000 V AC (Main) / 600 V AC/DC (Auxiliary) |
| Auxiliary Contacts | 1 NO + 1 NC |
| Reset Options | Manual or Automatic (selectable) |
| Compatible Contactors | A145, A185, AF145, AF185, AF190, AF205 |
| Protection Features | Overload, phase failure, and phase unbalance |
| Operating Temperature | -25°C to +70°C (-13°F to 158°F) |
