Product appearance may vary. Refer to the description and specs for complete information
Baldor Reliance EM3546T-8 three-phase industrial electric motor rated at 1 HP, 1775 RPM. Features 230/460V dual voltage capability, 143T frame size, and 3.5A full load amps at high voltage. 60Hz operation with 4-pole configuration. Specification number 35AA001G118G1. Freight shipping required.
Manufacturing Part #
EM3546T-8
Availability:
1
In stock
Product type:
Motors
- $914.69
- $914.69
- (-0%)
- Unit price
- per
Shipping Details
This heavy-duty item requires specialized freight shipping. Please note that additional freight charges apply and are to be paid by the customer.
Baldor Reliance EM3546T-8 three-phase industrial electric motor rated at 1 HP, 1775 RPM. Features 230/460V dual voltage capability, 143T frame size, and 3.5A full load amps at high voltage. 60Hz operation with 4-pole configuration. Specification number 35AA001G118G1. Freight shipping required.
| Manufacturer | Baldor-Reliance (ABB) |
| Part Number (MPN) | EM3546T-8 |
| Spec Number | 35AA001G118G1 |
| Output @ Frequency | 1.000 HP @ 60 Hz |
| Phase | 3-Phase |
| Synchronous Speed @ Frequency | 1800 RPM @ 60 Hz |
| Full Load Speed | 1775 RPM |
| Voltage @ Frequency | 200 V @ 60 Hz |
| Frame Size | 143T |
| Enclosure Type | TEFC (Totally Enclosed Fan Cooled) |
| Mounting | Rigid Base (Foot Mount) |
| Full Load Amps | 3.6 A @ 200V |
| Service Factor | 1.15 |
| Insulation Class | Class F |
| Efficiency @ 100% Load | 85.5% |
| Power Factor | 67 |
| Bearings | Ball Bearing (6205 DE / 6203 ODE) |
| Shaft Grounding | No Shaft Grounding |
| Frame Material | Steel |
| Net Weight | 35 lbs. |
| Application | General Purpose, Pumps, Fans, Compressors |
