Manufacturing Part #
611.1431.060
Availability:
3
In stock
Product type:
Cable Pull Switches
- $385.00
- $385.00
- (-0%)
- Unit price
- per
Free standard shipping on orders over $100
| Manufacturer & Part Number |
Bernstein 611.1431.060 (SID-UV1Z P-RAST)
|
| Product Type | Standard cable pull switch with tension monitor |
| Contact Configuration | 1NO + 1NC |
| Contact Type | Slow action |
| Housing Material | Aluminum die-cast body with aluminum-plated cover |
| Actuator Type | Pull ring (Zinc die-cast) |
| Rated Insulation Voltage (Ui) | 400V AC |
| Thermal Current (Ith) | 16A |
| IP Rating | IP65 |
| Mechanical Life | 1,000,000 cycles |
| Operating Temperature | -30°C to +80°C |
| Cable Entrance | 2 x M20 x 1.5 |
