Product appearance may vary. Refer to the description and specs for complete information
Manufacturing Part #
11BGF0910A02460
Availability:
4
In stock
Product type:
Contactor
- $79.20
- $79.20
- (-0%)
- Unit price
- per
Free standard shipping on orders over $100
| Manufacturing Part Number | 11BGF0910A02460 |
| Amperage Rating | 9 A (AC-3 motor switching); 20 A (AC-1 general purpose) |
| Coil Voltage | 24 VAC, 60 Hz (also compatible with 24 VAC 50 Hz, but rated for 60 Hz) |
| Number of Poles | 3 main power poles (3NO) |
| Auxiliary Contacts | 1 Normally Open (1 N.O.) integrated |
| Voltage Rating | 690 VAC maximum (IEC) |
| Power Rating | 3 HP at 230 V, 5 HP at 460 V (3 Phase UL ratings) |
| Termination Type | Screw terminals or Quick Connect (Faston) |
| Mounting | 35mm DIN rail or panel mounting |
| Standards & Certifications | UL Recognized, CSA, IEC, CE compliant |
