Product appearance may vary. Refer to the description and specs for complete information
Manufacturing Part #
31L48MM240
Availability:
6
In stock
Product type:
Time Delay Relays
- $107.80
- $107.80
- (-0%)
- Unit price
- per
Free standard shipping on orders over $100
| Manufacturer Part Number | Lovato Electric 31L48MM240 |
| Product Series | L48 Series (Model L48M) |
| Relay Type | Multifunction & Multiscale Electronic Timing Relay |
| Number of Functions | 10 selectable functions (including On-delay, Off-delay, Flashing, and Step-by-step) |
| Contact Configuration | 2 C/O (DPDT) changeover contacts |
| Rated Supply Voltage | 24VAC/DC, 110VAC, and 220–240VAC (50/60 Hz) |
| Contact Current Rating | 5A resistive load (Ith) |
| Time Delay Range | Adjustable from 0.05 seconds to 10 days |
| Terminal Style | 11-pin plug-in connector |
| Mounting Style | Flush mounting (48x48mm) or socket plug-in |
| Local Signaling | LED indicators for power status and relay state |
| Safety Features | IP40 front panel protection; self-extinguishing polyamide housing |
