Product appearance may vary. Refer to the description and specs for complete information
Manufacturing Part #
CA3KN31JD
Availability:
5
In stock
Product type:
Contactor Relays
- $68.42
- $68.42
- (-0%)
- Unit price
- per
Free standard shipping on orders over $100
| Manufacturer Part Number | CA3KN31JD |
| Contact Configuration | 3 NO + 1 NC (3 Normally Open + 1 Normally Closed) |
| Control Circuit Voltage | 12V DC (Standard Coil) |
| Contact Current Rating | 10A at ≤ 50°C |
| Rated Operational Voltage | ≤ 690V AC (≤ 400 Hz) |
| Mechanical Durability | 20,000,000 cycles |
| Maximum Operating Rate | 10,000 cycles/hour |
| Operating Temperature | -25°C to +50°C (-13°F to 122°F) |
| Mounting Support | 35mm DIN rail or Plate mount |
