Product appearance may vary. Refer to the description and specs for complete information
Manufacturing Part #
782XBXM4L-120A
Availability:
4
In stock
Product type:
Power Relays
- $16.50
- $16.50
- (-0%)
- Unit price
- per
Free standard shipping on orders over $100
| Manufacturer Part Number | 782XBXM4L-120A |
| Contact Configuration | DPDT (2 Form C / 2 NO + 2 NC) |
| Coil Voltage | 120V AC (60 Hz) |
| Contact Current Rating | 15A at 120–277V AC / 15A at 28V DC |
| Coil Resistance | 4,430 Ohms (+/- 10% at 20°C) |
| Average Coil Consumption | 1.4 VA |
| Response Time | 20 ms (Operate and Release) |
| Mechanical Durability | 10,000,000 cycles |
| Operating Temperature | -40°C to +55°C (-40°F to 131°F) |
| Terminal Type | Blade / Faston Terminals (8-pin) |
