Product appearance may vary. Refer to the description and specs for complete information
Manufacturing Part #
RZ7-FEY2QU23
Availability:
2
In stock
Product type:
Time Delay Relays
- $121.00
- $121.00
- (-0%)
- Unit price
- per
Free standard shipping on orders over $100
| Manufacturer & Part Number | Sprecher+Schuh / RZ7-FEY2QU23 |
| Product Series | RZ7-FE Series Electronic Timing Relays |
| Relay Function | Star-Delta (Wye-Delta) timing function |
| Timing Range | Adjustable from 0.05 seconds to 10 minutes |
| Contact Configuration | 1 NO (Star) + 1 NO (Delta) with a common pole |
| Rated Supply Voltage | 110–240V AC (50/60 Hz) and 24V DC |
| Contact Current Rating | 5A (Resistive load AC-1 at 250V) |
| Transition Time | Fixed 50ms dead interval between star and delta |
| Indicator Type | Bicolored LED for power status and timing state |
| Termination Style | Screw terminals (IP20 finger-safe protection) |
| Mounting Style | Standard 35mm DIN Rail or surface mount |
